Plant Facility

plant1

SMT- Section

Production Machinery

S.NO Machine Name Brand & Model Sr.No Status
1 PCB Loader – Un-loader Panasonic- B.S.F-236A MT/ M-01 In Use
2 PCB Cleaning  M/C Nutech-NTM5000M MT/ M-02 In Use
3 Paste printing M/C- Auto Spped Line-UP2000-HI MT/ M-03 In Use
4 SMT Pick & Place M/C I-pulse MT/ M-04 In Use
5 SMT Pick & Place M/C I-pulse MT/ M-05 In Use
6 Reflow Oven Vitronics-MR2 MT/ M-06 In Use
7 Paste oprinting M/C-semi Auto Clichn -SP500+ MT/ M-07 In Use
8 Pick & Place M/C Philips – Spphire MT/ M-08 In Use
9 Fine Placer M/C Philips- Topaz MT/ M-09 In Use
10  ICT Tester Kyoritsu Test System- Focus-2000 MT/ M-10 In Use
11 Hot Oven/ baking chamber Binder- DIN12880 MT/ M-11 In Use
12 Solder Paste Mixer Wenzhou Zhenbang MT/ M-12 In Use
13 Wave Soldering Machine Stallion-µ321 MT/ M-13 In Use
14 RoHS Solder pot with Temp control Estovir MT/ M-14 In Use
15 AOI  -Auto Optical Inspection m/c Yamaha-YSI-12 MT/ M-15 In Use
16 Dehumidifier Totaline MT/ M-16 In Use

Plant Machinery

  Equipment Name Brand & Model Sr.No Status
1 Reflow Profiler KIC-Start2 MT/ 022 In Use
2 AOI  -Auto Optical Inspection m/c Mirtec-MRV2000 MT/ 023 Not In Use
3 LCR Meter LCR-4090Q MT/ 024 In Use
4 Multimter Fluke-101 MT/ 025 In Use
5 Power & Harmonic Analyzer Meco- PHT -4545 MT/ 026 In Use
6 Clamp Meter Fluke-101, Mastech-M92A MT/ 027 In Use
7 LUX Meter HTC_ LX-101A MT/ 028 In Use
8 Two channel Digital Storage Oscilloscape Tektronix TBS1062 MT/ 029 In Use
9 Regulated DC Power supply(0-60Vdc/5Amp) Aplap- LD6410 MT/ 030 In Use
10 Programable DC Power Ssupply TDK -GEN 61-25, EHFP MT/ 031 In Use
11 Digital  Temperature & Humidity Meter Mextech-TM-01, HTC-01 MT/ 032 In Use
12 Hot Air Gun/ Rework satation Mectoo-M936Am Hakko MT/ 033 In Use
13 Temperature Control Soldering Iron Mectool-M936A, OKI-PS-900 MT/ 034 In Use
14 Magnifier Lamps Dyanamic-4x MT/ 035 In Use
15 Variac -10A, 0-260Vac PCS Dimmer Tech MT/ 036 In Use
16 Depaneling Machine Nil MT/ 037 In Use
17 Wrist Strap & Footwear Tester WSFT-01 -( 08148) MT/ 038 In Use
